StarTech.com Running low on expansion slots Merge USB 3.0 and GbE into a single PCIe combo ca – PEXUSB3S3GE
Running low on expansion slots Merge USB 3.0 and GbE into a single PCIe combo ca
Features
Technical Specifications
| Brand | : | StarTech.com |
| Manufacturer Part Number | : | PEXUSB3S3GE |
| Product Category | : | Network Switches |
| UPC | : | 065030860796 |
| Connectivity technology | : | Wired |
| Host interface | : | PCI Express |
| Interface | : | Ethernet |
| Ethernet LAN (RJ-45) ports | : | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity | : | 3 |
| USB version | : | 3.2 Gen 1 (3.1 Gen 1) |
| PCI version | : | 2.0 |
| PCI Card form factor | : | Full-height (low-profile) |
| Maximum data transfer rate | : | 5000 Mbit/s |
| Networking standards | : | IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Ethernet LAN | : | Yes |
| Ethernet LAN data rates | : | 10,100,1000 Mbit/s |
| Cabling technology | : | 10/100/1000BaseT(X) |
| Wake-on-LAN ready | : | Yes |
| Auto MDIX IEEE | : | Yes |
| Full duplex | : | Yes |
| Jumbo frames support | : | Yes |
| Auto-negotiation | : | Yes |
| Jumbo frames | : | 9000 |
| VLAN tagging | : | Yes |
| Internal | : | Yes |
| Product color | : | Metallic, Red |
| Chipset | : | Renesas / NEC - µPD720201, Realtek - RTL8153 |
| LED indicators | : | Activity, Link |
| Mean time between failures (MTBF) | : | 1920042 h |
| Certification | : | CE, FCC |
| Windows operating systems supported | : | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 |
| Linux operating systems supported | : | Yes |
| Server operating systems supported | : | Windows Server 2008 R2, Windows Server 2012 |
| Operating temperature (T-T) | : | 5 - 50 °C |
| Storage temperature (T-T) | : | -25 - 70 °C |
| Operating relative humidity (H-H) | : | 20 - 80% |
| Width | : | 18 mm |
| Depth | : | 77 mm |
| Height | : | 120 mm |
